Description
The Tube Type Air Diffuser is a proven and dependable technology commonly utilized in the treatment of both municipal and industrial wastewater. Designed explicitly for Effluent Treatment Plants (ETP), these diffusers are known for their efficiency and reliability. They are engineered to provide minimal pressure drop while delivering high oxygen transfer efficiency. Additionally, their even bubble distribution ensures adequate aeration, optimizing the overall performance of wastewater treatment systems. This makes Tube Type ETP Plant Diffusers a preferred choice for enhancing the efficiency and sustainability of wastewater treatment processes.
Advantages of Tube Type Air Diffuser:
- Free Cost-Estimates & Designs: Greenify offers free cost estimates and evaluations without obligations to make sure that the Greatech Disc diffuser is a perfect fit for every project.
- High-Quality Aeration Products: Greenify aeration systems are well-known in the industry for their outstanding performance and quality, with a wide range of models available to meet your specific treatment requirements flexibly.
- Quality and Innovation: Greenify has a tradition of providing superior quality products and lasting innovation. Everything from our diaphragms to our fittings and air distribution lines is subjected to rigorous quality testing.
- Installation and Commissioning: A professional project management team ensures that each project is completed on time and with the highest quality. The installation and commissioning of each project is guided by an experienceengineer.
| Greatech Tube Type Air Diffuser | ||||
| Model No. | OD x ID x Length (mm) | PCS | Air Flow Operation (L/min) | Overall Length (mm) |
| GTD-S250 | 70 x 50 x 250 mm | 1 | 60 ~ 90 | 310 |
| GTD-S500 | 70 x 50 x 500 mm | 1 | 120 ~ 180 | 560 |
| GTD-D500 | 70 x 50 x 500 mm | 1 | 240 ~ 360 | 575 |
| GTD-D1000 | 70 x 50 x 1000 mm | 1 | 480 ~ 720 | 1075 |
| Components | Holder | Porous Part | End Cap | Packing | Connecting Rods, Washers & Nuts |
| Material | ABS | PE | ABS | Rubber | SUS 304 |
| Pipe Fittings: | |||||
| Single Section : (25A) 1″ for GTD-S500 | |||||
| Double Section: (32A) 1″ for GTD-D500 |
Tube Type Fine Bubble Air Diffuser
Model: GTD-D500*65
Type: Tube
Size: 500mm
MOC: EPDM
Connector: ¾” NPT Male Threat
Bubble Size: 1-2 mm
Design Flow: 1.7-6.8 m3/Hr
Flow Range: 2-14 m3/Hr
SOTE: =40% (06 m Submerged)
SOTR: =0.90 Kg O2/h
SAE: =8.6 Kg O2/Kw.h
Headloss: 2200-4800 Pa
Service Area: 0.75-2.5 m2/Pcs
Service Life: Minimum 05 Year
Brand: GREATECH/Taiwan.
Coarse bubble air diffusers are widely used due to their combination of high oxygen transfer efficiency and low energy requirements, making them a preferred choice for wastewater treatment plants.
Contact
For the Special Price of Greatech Diffuser, Contact Us. Cell: 01771646625 (WhatsApp)
